stiltz home lift
The STILTZ home lift is fully imported from UK by the original STILTZ Ltd company, with no pit, no shaft required, and built to high safety standards.
GENERAL FEATURES
- Roped Drum Motor
- Speed: 0.1 – 0.15 m/s
- Travel up to 4 m
- Up to 2 Floors (G-1)
- No pit needed
- Headroom: 2250 mm
- Power: Single Phase – 220V
- Full height doors or half height door with light curtains
- 2 Remote controlsOptional
- Thru car ( 2 Doors)
- Indoors Only
- Fully Imported from UK
Flexible Installation & Exceptional Design
Stiltz Home Lifts can be installed almost anywhere in your home.
Manufactured to the highest quality standards, these freestanding lifts feature a compact footprint and a unique self-supporting rail design, eliminating the need for a supporting wall.
Stiltz also offers a range of wheelchair-accessible models, ensuring comfort and independence for every user.
The Duo+ Home Lift is a fun and versatile alternative to a stairlift and is also a great solution for homeowners exploring ways of future-proofing their property. Designed to transport two people up one floor in under 30 seconds, the Duo+ is a stylish, compact home lift which is elegantly curved and designed to compliment any style of décor.
- Perfect stair lift alternative
- Small footprint of under 7 sq. ft.
- Carries two people
- Also available as Classic, Vista or Thru Car
The Stiltz Trio+ Home Lift is our wheelchair lift and is perfect for the less mobile. Larger than the Duo but still surprisingly compact, all Trio home elevator models are designed for wheelchair users with wider entry and exit points and a ramp included as standard. The Trio+ also provides lift solutions for those with disabilities and people with walking frames.
- Big enough for a standard wheelchair
- Small footprint of under 13.5 sq. ft.
- Carries three people
- Also available as a Thru Car
Movement Safety Sensors
All Stiltz Home Lifts are fitted with safety sensors in the base and top lid of the lift car. These sensors detect obstructions above or below the lift. If anything is positioned on the lift lid, the lift won’t move upwards. If the lift is in use in either direction and meets an obstruction, it will come to a smooth stop until the obstruction is removed.
An additional sensor included as standard is a ‘light curtain’. This is located either side of the entrance of the lift car (and if you have a half height door, it includes the gap between the door and the top of the lift car) and ensures if anything crosses the entrance threshold of the lift while in motion, the lift will stop automatically.
What stops the lift from falling?
As our Home Lifts require no structural work to the property and no load-bearing wall, we often get asked what stops the lift from falling? The weight of the Home Lift is carried by two very strong steel cables, in the extremely unlikely event they lose tension or break, our patented Fall Arrest Mechanism kicks in, and prevents the car from falling, or even moving at all.
What do I do if I experience any problems with my Home Lift?
Every Stiltz Home Lift is installed with its own integrated phone, so in the unlikely event of a breakdown, help is only a phone call away. The safety of our customers is paramount and that why we have a full range of safety features included in every lift as standard.
All Stiltz residential lifts are fully electric and powered by simply plugging them straight into a standard 13 amp power socket just like any other household appliance.
Manufactured to the highest quality, freestanding, have a compact footprint, and travel on a unique rail design. With no supporting wall required.
With no noisy external hydraulics or vacuum drive systems to worry about, the Stiltz Home Lift is whisper quiet and standard remote controls allow you to move suitcases, heavy items, boxes, or anything else you need an extra pair of hands with.
Stiltz passenger lifts are fully compliant with all European safety standards and features include a battery back-up, full or half height doors, obstruction sensors, key lock to stop unauthorised use, an optional seat and grab bar. Stiltz also supply a range of wheelchair lifts.
Standard Specifications
- Finish: Light grey.
- Half-Height Door: The door is interlocked and matches the finish of the elevator.
- 2 x Remote Controls: Call and send the elevator remotely; also, use it to move heavy
or awkward items between floors. - One-Year Parts Warranty: All Stiltz Elevators carry a standard 12 months parts warranty.
- Internal LED Downlights: Programmed to turn when the user has called or entered the elevator; will remain on for the entire journey.
- Battery Back-Up System If there is a power cut while using the elevator, it can be driven to the lower level of the home and will then wait until the power comes back on to resume normal service.
- Half-Height Light Curtain: Projects the opening above the half-door from obstructions; the lift will not move until the obstruction has been removed and the light curtain is clear.
- Interior Telephone: Help is just a phone call away. Every lift comes standard with a landline phone; a cell phone is available as an option.
- Fold-Down Seat: A stylish molded plastic seat is an option; simply lift the seat out of the way when not in use.
- Interior Grab Rail: Offers increased security for the occupants of the elevator.
- Full-Height Door: An interlocked door that replaces the half-height door option.
- Half Height Light Curtain: An obstruction sensor is situated at the entrance of our elevators. If this barrier is crossed at any time, the elevator will immediately stop.
- Safety Lid Cover: This crucial feature covers the aperture in the floor when the elevator is in the downstairs position. It is strong enough to stand on, and you can place your original flooring on top to blend in.
- Key Switch Operation: This feature allows the owner to lock out the elevator if the need arises. This is commonly used when going away on holiday or when the grandchildren are around.
- Top & Bottom Safety Pans: Using our obstruction sensors, a Stiltz elevator can detect objects above or below the elevator, causing it to immediately stop.
- Hold-To-Run Controls: Operating a Stiltz Elevator requires constant pressure to the controls. This allows the user to ‘drive’ the elevator and feel in total control.
- Weight Limit Sensors: The Trio Alta home elevator is limited to 500lbs. The elevator detects anything exceeding this limit and will not travel.
- Out Of Balance Sensors: Sensors will detect if the elevator is ever out of balance and prevent the unit from travelling.
- Fall Arrest Mechanism: This patented system prevents the car from falling in the unlikely event of the steel ropes going slack.
- Emergency Stop Button: This button is front and center for the user in the event of an emergency.
| Drive | Roped drum, braked gear motor drive |
| Power Supply | Dedicated 220V AC line required, like most major appliances |
| Maximum Load | 375lbs / 2 persons standing or 1 person sitting |
| Maximum Travel | 177 – 3/16″ |
| Entrance Security | Half height light curtain with obstruction sensor |
| Maximum Speed | 5.9 inches / second |
| Warranty | 1 year parts |
| Rope Diameter | 6mm galvanized steel rope |
| Additional Sensors | Out of balance; overload; top / bottom obstruction |
| Lighting Type | 2 x 3w LED downlights |
| Landing Call Stations | 2 wireless remote controls |
| Installation | Typical installation takes one day after home modification is complete |
| Operation | Hold-to-run controls |
| Configuration | Single entry door or ThruCar (Duo Classic only) |
safety features
- Stiltz Lift Will Detect Objects above or below the lift and will stop immediately should something or someone stand on the lift car lid upstairs or below the lift as it descends.
- Battery Backup System
- Out-of-Balance Sensors
- Hold-to-Run or Auto-Run Controls
- Top & Bottom Safety Pan
- Fall Arrest Mechanism
- Emergency Stop Button
- Mobile Phone
- Light Curtain
- Weight Limit Sensors
- Key Switch Operation
- One year warranty
Manufactured to the highest quality, domestic lifts from Stiltz Homelifts are freestanding, have a compact footprint, and travel on a unique rail design. With no supporting wall required. Stiltz also supply a range of wheelchair lifts.
Small Footprint
The Stiltz Home Lift has one of the smallest footprints of any lift in the world.
Whisper Quiet
Unlike other domestic lifts, Stiltz doesn’t use noisy hydraulics or vacuum systems, making them quieter than many stairlifts.
Fast Installation
Stiltz lifts can fit under most doorways and ceilings, and be pieced together quickly, with a typical installation taking only one day.
Low Power Consumption
All our lifts plug straight into a standard 13-amp power socket, just like any other appliance in your home.
Wheelchair Accessible
Atiltz Trio provides enough space for a person in a wheelchair with an attendant or for up to 3 adults
Unique Guide System
Stiltz Home Lifts travel on self-supporting rails eliminating the need for load-bearing walls.
stiltz wins 2020 • home lift company Queen's Award for International Trade
Stiltz Home Lifts has been honored with the Queen’s Award for Enterprise: International Trade 2020 — one of the highest distinctions awarded to a UK business.
This prestigious recognition celebrates Stiltz’s outstanding performance in global markets and reflects the company’s commitment to innovation, quality, and excellence in home lift solutions.
Talk to Our Lift Experts
Every home deserves a lift designed around it. Our specialists will help you select the perfect solution—tailored to your space, architecture, and lifestyle—ensuring exceptional comfort, safety, and design from start to finish.
